Usage

One uses normal DataFrames and with a Vector of GeoInterface.jl compatible geometries as a column.

using GeoDataFrames

points = GeoInterface.Point.(rand(10), rand(10))  # point geometry
df = DataFrame(geometry=points, name="test");

Unlike geopandas, there's no special GeoDataFrame type here.

Reading

Reading into a DataFrame is done by the read function. It simply takes a filename.

df = GeoDataFrames.read("test_points.shp")
10×2 DataFrame
 Row │ geometr                name
     │ IGeometr…           String
─────┼────────────────────────────
   1 │ Geometry: wkbPoint  test
   2 │ Geometry: wkbPoint  test
   3 │ Geometry: wkbPoint  test
   4 │ Geometry: wkbPoint  test
   5 │ Geometry: wkbPoint  test
   6 │ Geometry: wkbPoint  test
   7 │ Geometry: wkbPoint  test
   8 │ Geometry: wkbPoint  test
   9 │ Geometry: wkbPoint  test
  10 │ Geometry: wkbPoint  test

Using ArchGDAL

When using the default ArchGDAL driver, you can also specify the layer index or layer name in opening, useful if there are multiple layers:

GeoDataFrames.read("test_points.shp"; layer=0)
GeoDataFrames.read("test_points.shp"; layer="test_points")

Any keywords arguments are passed on to the underlying (possibly native) driver. For reading with ArchGDAL, that corresponds to the read function:

GeoDataFrames.read("test.csv", options=["GEOM_POSSIBLE_NAMES=point,linestring", "KEEP_GEOM_COLUMNS=NO"])

Extensions

As soon as you import a native driver extension package, it will override the default ArchGDAL driver for reading/writing files of the corresponding format. You can get the old behaviour back by explicitly using the `ArchGDALDriver` when reading/writing files like so: `read(GeoDataFrames.ArchGDALDriver(), fn; kwargs)`.

Writing

Write a DataFrame is done by the write function. It simply takes a filename, and a DataFrame with a geometry column.

points = GeoInterface.Point.(rand(10), rand(10))
df = DataFrame(geometry=points, name="test");
setcrs!(df, EPSG(4326))  # optional: set coordinate reference system
GeoDataFrames.write("test_points.gpkg", df)

Note that any Tables.jl compatible table with GeoInterface.jl compatible geometries can be written by GeoDataFrames. If you have geometry column(s) named other than geometry, you can pass so at write, setting it with setgeometrycolumn if the table supports metadata, or by defining GeoInterface.geometrycolumns on your table. Multiple geometry columns, when enabled by the driver, can be provided in this way.

table = DataFrame(geom=GeoInterface.Point.(rand(10), rand(10)), name="test")
GeoDataFrames.setgeometrycolumn!(table, :geom)  # set geometry column
GeoDataFrames.write("custom.gpkg", table)
# OR
table = [(; geom=GeoInterface.Point(1.0, 2.0), name="test")]  # Also a valid table, but no metadata
GeoDataFrames.write("custom.gpkg", table; geometrycolumn=:geom)

In the same way, if your geometry doesn't contain a CRS, and the table supports metadata, you can set the CRS using setcrs!, or by defining GeoInterface.crs on your table. Otherwise, you can pass the crs keyword at write. Define the coordinate reference system with GeoFormatTypes.jl:

table = DataFrame(geometry=GeoInterface.Point.(rand(10), rand(10)), name="test")
GeoDataFrames.setcrs!(table, EPSG(4326))  # set coordinate reference system
GeoDataFrames.write("with_crs.gpkg", table)
# OR
table = [(; geometry=GeoInterface.Point(1.0, 2.0), name="test")]  # Also a valid table, but no metadata
GeoDataFrames.write("with_crs.gpkg", table; crs=EPSG(4326))

Using ArchGDAL (default)

When using the default ArchGDAL driver, you can also set options such as the layer_name.

GeoDataFrames.write("test_points.shp", df; layer_name="data", crs=EPSG(4326))

You can update existing geopackage files by adding new layers. Set the update=true option and provide a unique layer_name:

GeoDataFrames.write("test.gpkg", df; layer_name="foo", update=true)

To overwrite an existing layer, either use a new layer name or pass "OVERWRITE"=>"YES" in the options:

GeoDataFrames.write("test.gpkg", df; layer_name="existing_layer", update=true, options=Dict("OVERWRITE"=>"YES"))

The most common file extensions are recognized, but you can override this or write uncommon files by setting the driver option. See here for a list of (short) driver names.

GeoDataFrames.write("test_points.fgb", df; driver="FlatGeobuf", options=Dict("SPATIAL_INDEX"=>"YES"))

The following file extensions are automatically recognized in the ArchGDAL driver:

    ".shp" => "ESRI Shapefile",
    ".gpkg" => "GPKG",
    ".geojson" => "GeoJSON",
    ".vrt" => "VRT",
    ".sqlite" => "SQLite",
    ".csv" => "CSV",
    ".fgb" => "FlatGeobuf",
    ".pq" => "Parquet",
    ".arrow" => "Arrow",
    ".gml" => "GML",
    ".nc" => "netCDF",

Using Extensions

As soon as you import a native driver extension package, it will override the default ArchGDAL driver for reading/writing files of the corresponding format. You can get the old behaviour back by explicitly using the `ArchGDALDriver` when reading/writing files like so: `write(GeoDataFrames.ArchGDALDriver(), fn, table; kwargs)`.
